WORKSHOP MANUAL SERVICE REPAIR SKODA FABIA MK2 (2007-2014) (EN)

This Product is a PDF Workshop manual for
SKODA FABIA II
2007 - 2014

TOPICS:

    General Body Repairs
    Body Repairs
    Body Work
    1.2/44 kW; 51 kW; 55 kW Engine
    1.2/44; 47; 51; 55 kW MPI Engine
    1,2/55 kW TDI CR Engine (Edition 02.2010)
    1.2/55 kW TDI CR Engine (Edition 01.2013)
    1.2/63 kW; 77 kW TSI Engine (Edition 02.2010)
    1,2/63; 77 kW TSI Engine (Edition 09.2012)
    1.4/132 kW TSI Engine
    1.4/51kW TDI; 1.4/59kW TDI Engine (12.2006)
    1.4/51; 59 kW TDI PD Engine (Edition 06.2011)
    1,4/63 kW MPI Engine (Edition 02.2011)
    1.4/63 kW MPI Engine (Edition 02.2007)
    1.5/77; 1.6/55; 66; 77 kW TDI CR Engine
    1.6/55 kW; 1.6/66 kW; 1.6/77 kW TDI CR Engine
    1.6/77 kW MPI Engine (Edition 03.2014)
    1.6/77 kW MPI Engine (Edition 12.2006)
    1.9/77 kW TDI PD Engine (Edition 01.2014)
    1.9 ltr./77 kW TDI PD Engine (Edition 12.2006)
     Automatic 6-speed gearbox 09G
    Automatic gearbox 0AM
    Gearbox 02R (Edition 2014)
    Gearbox 02R (Edition 12.2006)
    Gearbox 02T (Edition 05.2014)
    Gearbox 02T (Edition 12.2006)
    Gearbox 09G
    Gearbox 0AM-DSG
    Brake systems
    Axles, steering
    Wheels, Tyres
     Air conditioning system with refrigerant R134a
    Heating, Air conditioning
Electrical System
Electrical System – general notes
Fitting Locations

Wiring Diagrams

LANGUAGE: ENGLISH
